ماژول آدرس پذیر دو دوردی آدرس پذیر هوچیکی مدل CHQ-DIM2(SCI)
Model CHQ-DIM2(SCI) is a Dual Input Module designed to interface to a variety of inputs such as door contacts, sprinkler flow/door switches and plant equipment
The unit supports a resistive feature for the monitoring of the inputs when operating in Enhanced mode. Please check for panel support of this feature, failure to do so will regress this device into Compatibility mode where the inputs are not monitored.
Also available as a DIN Rail mountable version; both models feature an integral short-circuit isolator
A back box is also available (CHQ-BACKBOX) which, when used in conjunction with the CHQ-DIM2(SCI), increases the IP rating to IP65
- Single Loop Address
- Loop Powered
- 2 Independent Inputs for Monitoring of Volt Free Contacts
- Each Input can be Configured to Monitor either Normally Open or Normally Closed contacts
- DIN-Rail version available
- Both models feature an integral SCI
- Both models approved by LPCB
دانلود دیتاشیت ماژول آدرس پذیر دو ورودی HOCHIKI مدل CHQ-DZM(SCI)
دانلود راهنمای نصب محصولات HOCHIKI سری CHQ
