ماژول آدرس پذیر دو خروجی آژیر Hochiki مدل CHQ-DSC2/DIN(SCI)
Dual Sounder Controller – DIN Enclosure with SCI
Model CHQ-DSC2/DIN(SCI) is a Dual Sounder Controller, which has been designed to provide two sounder outputs (that can be driven separately) with full fault monitoring. The unit is supplied as a DIN enclosure but is also available as a boxed enclosure; both models feature an integral short-circuit isolator
The monitored input can be used for local power supply fault monitoring or as a general-purpose input. The unit utilises simple DIL switches for reliable addressing
Single loop address
Two independent sounder circuits
Each circuit fully monitored for open and short circuit faults
Each alarm circuit fused at 1 A
Auxiliary monitored input
Outputs are synchronised and can be driven continuously or intermittently
24 VDC auxiliary power required
Boxed module version available
Both models feature an integral short-circuit isolator
Both models approved by LPCB and VdS
دانلود دیتاشیت ماژول آدرس پذیر دو خروجی آژیر HOCHIKI مدل CHQ-DSC2/DIN(SCI)
